Schneider 5000W/5Kwa MPPT Inverter

Schneider 1.000W / 1 Kw Smart Inverter MPPT

Grid Connect Smart Inverter

These devices are inverter and charger that combine the functions of inverter, solar charger and battery charger to offer uninterrupted power supply in portable size. Its comprehensive LCD display offers user configurable and easily accessible button operation such as battery charging current, AC input or Solar input charging priority, and acceptable input voltage based on different applications. It allows you to directly use the Energy it receives in a sunny weather. Thus, less power is exerted on the System and the Battery.

Full sine Full wave inverter

Integrated MPPT solar energy charging feature

Configurable input voltage for home appliances and personal computer with LCD setting

Configurable battery charging current based on applications with LCD setting

Configurable AC/Solar Charger feature with LCD setting

Compatible with mains voltage or generator power

Auto restart while AC is regaining

Overload / Over Temperature / Short circuit protection

Intelligent battery charger design for optimized battery performance

TECHNICIAL SPECIFICATIONS

(INPUT) Operating Voltage: 230 VAC

Adjustable Voltage Range: 90-280 VAC

Frequency Range: 50 Hz / 60 Hz

(OUTPUT)Max Efficiency: 93%

Inrush Power: 2000 VA

(BATTERY) Voltage : 12 VDC

Overload Protection: 10 VDC

Max Mains Charge Current: 20 A

(SOLAR CHARGING) Current: 50 A

Open Circuit Voltage (max): 40 VDC

Stand-by Power Consumption: 1W

Dimension(mm): 95*240*316

Weight(kg): 5.0

Origin : Germany

Warranty : 6 Years

Schneider 3000 W / 3 Kw Smart Inverter MPPT

Grid Connect Smart Inverter

These devices are inverter and charger that combine the functions of inverter, solar charger and battery charger to offer uninterrupted power supply in portable size. Its comprehensive LCD display offers user configurable and easily accessible button operation such as battery charging current, AC input or Solar input charging priority, and acceptable input voltage based on different applications. It allows you to directly use the Energy it receives in a sunny weather. Thus, less power is exerted on the System and the Battery.

Full sine Full wave inverter

Integrated MPPT solar energy charging feature

Configurable input voltage for home appliances and personal computer with LCD setting

Configurable battery charging current based on applications with LCD setting

Configurable AC/Solar Charger feature with LCD setting

Compatible with mains voltage or generator power

Auto restart while AC is regaining

Overload / Over Temperature / Short circuit protection

Intelligent battery charger design for optimized battery performance

TECHNICIAL SPECIFICATIONS

Output Power: 3000 Watts Continuous

Peak Power: 4800 Watts

Output Voltage: AC-230V 50 Hz

Output Wave Mode/Type: Sine/Sine Wave Mode

Input Voltage: 24V DC nominal

Battery High Voltage Alarm: <33V DC

Battery Low Voltage Shutdown: <20.2V DC

Automatic Power-Out Protection

LED Indicator Panel, see fault indication

Size: 100*285*334mm

Weight: 6.4 Kg

Battery charging feature from mains electricity or generator 0-20A

Origin : Germany

Warranty : 6 Years

Electric Charging Stations for home or private properties (indoor or outdoor)

EVlink Wallbox is weatherproof and can be used in harsh environments, at home and in private properties (residential, corporate car park, hotel...). Our range is made up of Wallbox Standard and Wallbox Plus. In addition to all the functions available in the Wallbox Standard, the Wallbox Plus is now equipped with a built-in protection against direct currents and a device that prevents exceeding the subscribed electrical power (only available in France with electronic auxiliary meters).
